AM-2000 Plus
Dental Microscope
The AM-2000 Plus Dental Microscope is our most upgradeable dental microscope with optional accessories including cameras, beam splitter, laser filter, and more.
- Wide magnification range (2.5x to 20x).
- LED illumination with coaxial lighting.
- Hands-free operation available.
- Focusing Speed
- Zoom Speed
Key Features
Integrated 90° binocular extender allows doctors to maintain an upright posture during surgery, reducing strain on the back, neck, and shoulders for extended procedures.
Advanced pendulum rotation mechanism provides smooth, precise positioning and maintains optimal viewing angles throughout surgical procedures.
Professional beam splitter system (2:8/5:5 ratio) enables simultaneous observation and documentation while maintaining optimal light distribution.
High-definition 4K camera with advanced CMOS sensor and image processing technology delivers crystal-clear, detailed video results for documentation and teaching.
Lengthened horizontal distance of the eye point significantly increases the operating space, providing surgeons with greater freedom of movement.
Superior optical system provides clearer and more detailed microscopic images, enabling doctors to view the surgical area with exceptional accuracy.
AM-2000 Plus Dental Microscope
As our base model, the AM 2000 + offers all of the most important features needed at a base price that other
manufacturers can’t match without endless “add-ons.”
AM-2000 Plus Dental Microscope Description
The AM-2000 Plus Dental Microscope is our most upgradeable dental microscope with optional accessories including cameras, beam splitter, laser filter, and more. The convenient modular design makes the AM-2000 the perfect entry point to microscope enhanced dentistry. Alltion’s wide variety of accessories allows your dental microscope to adapt and evolve to your needs.
20 seconds to finish a full-arch scan. A scanner that boosts your confidence by making everything simple and fast.
Integrated Flexible Optics Rotating Assembly (FORA)
FORA including 90°binocular extender, pendulum rotation device and beam splitter (2:8/ 5:5) It allows operator to remain his natural and straight posture while he is observing the patient with a certain angle
Integrated 90-degree Binocular Extender
Lengthen the horizontal distance of the eye point to increase the operating space. Integrated 90°binocular extender allows the doctor to maintain a upright posture during the surgery, reducing the burden on the back, neck and shoulder.
AM-2000 Plus Dental Microscope Specifications
| Specification | AM 2000 PLUS |
|---|---|
| Magnification | Manual 5 steps magnification, 0.4, 0.6, 1.0, 1.6, 2.5, magnification range: 1.7x~19x |
| Objective Lens | 198-455mm Variable objective lens |
| Eyepiece | 12.5x/18B, Diopter adjustment range: +7D; 10x/21B, diopter adjustment range: -8D~+6D for option |
| Binocular | 180° Inclined binocular head, f=170mm, interpupillary distance adjustment range: 50~75mm |
| Pendulum Rotation Device | Standard, ±23° |
| Integrated Depth of Field Strengthen Device | Integrated depth of field strengthen mode |
| Object Illumination(x) | Max>80000 lux |
| LED | Color temperature 5500k, color rendering index 85% |
| Illumination Mode | Orange filter, green filter, large/medium/small spot |
| Electrical System | 12V DC power supply |
| Built-In Camera | Built-in 4k camera system |
| Weight | 85KG (with mobile floor stand) |
